plastic round/ flat/ danline/ split yarn making machine

Plastic round/ flat/ danline/ split yarn making machine   Usage: This set of machine is a professional yarn drawing line, which is mainly used for producing PP, HDPE monofilament yarn used for making Rope, twine, Fishing Net, etc...   Characters: This line consists of extruder, the first stretching device, heating extension board, the second stretching device and coiling machine. The matching devices for production process are complete, so it can continuously finish the whole procedures from putting material to coil yarn onto bobbins...   According to different technological requirements, set and automatically control the heating temperature of screw cylinder and die head. The temperature can be adjusted according to different kinds of materials.   Adopts rotating needle roller, which can split the stretched yarns into Net shape in order to make the yarns soft during next procedure of making ropes.   Technical specifications:

Model	YSJ-45	YSJ-50	YSJ-65	YSJ-70	YSJ-80
Dia.of Screw(mm)	45	50	65	70	80
L/D of screw	28:1	28:1	28:1	28:1	28:1
Rotate speed of screw(r/min)	5-75	5-75	5-75	5-75	5-75
Power of main motor(Kw)	7.5	11	15	18.5	22
Heating power of main motor (kw)	12	13.5	15	18	20
Dia. of spinneret hole(mm)	0.8-12	0.8-12	0.8-12	0.8-12	0.8-12
Quantity of spinneret hole(pcs)	60-100	80-120	110-150	160-220	200-300
Output(kg/h)	25-30	30-45	40-6	50-70	60-80



Contact us if you need more details on Yarn Making Machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Plastic Round Yarn Making Machine、Yarn Machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
